Specifications
Specifications
TF545P PETROL TILLER Art no: 967 63 93‑02 | |
---|---|
Engine | TF545P PETROL TILLER Art no: 967 63 93‑02 |
Net power at preset rpm Energy | 5 kW |
Air filter type | Paper |
Fuel tank volume | 6 l |
Power/fuel type | Petrol |
Cylinder displacement | 270 cm³ |
Capacity | |
Working width | 110 cm |
Working depth | 30 cm |
Tine diameter | 360 mm |
Number of tines | 8 |
Rotational speed (min/max) min | 63 rpm |
Rotational speed (min/max) max | 145 rpm |
Cultivator type | Front-tine |
Equipment | |
Rubber wheels | Included |
Transport wheel/s | Not available |
Foldable handlebar | Yes |
Horizontally adjustable handlebar | Yes |
Vertically adjustable handlebar | Yes |
Emission | |
Exhaust emissions (CO₂ EU V) | 610 g/kWh |
Transmission | |
Transmission type | Direct Clutch |
Transmission steps reverse | 2 |
Transmission steps forward | 4 |
Dimensions | |
Weight (complete product w/o side packed articles) | 113 kg |
Electric information | |
Engine name | Husqvarna Engine |
