Specifications
Specifications
P 525D (2015-) with factory assembled cabin Art no: 967 60 21‑01 | |
|---|---|
| Cutting deck | P 525D (2015-) with factory assembled cabin Art no: 967 60 21‑01 |
Uncut circle | 58 cm |
Cutting width, min | 132 cm |
Cutting width, max | 155 cm |
Cutting height min | 30 mm |
Cutting height max | 112 mm |
Blade engagement | Electric clutch |
| Engine | |
Power/fuel type | Diesel |
Net power at preset rpm Energy | 18,7 kW |
Motor/engine manufacturer | Kubota |
Engine name | D1105 |
Cylinder displacement | 1 123 cm³ |
Cylinders | 3 |
Engine cooling | Liquid |
Engine lubrication type | Pressure with Oilfilter |
Oil filter | Yes |
| Dimensions | |
Tyre dimensions, front | 20x10-10 |
Tyre dimensions, rear | 20x10-10 |
Wheelbase | 106 cm |
Ground clearance | 140 mm |
Base machine, length | 226,9 cm |
Base machine, width | 125,1 cm |
Base machine, height | 200,8 cm |
| Vibration | |
Vibration level steering wheel | 1,7 m/s² |
Vibration level seat | 0,7 m/s² |
| Drive system | |
Transmission type | Hydrostatic |
Transmission manufacturer, rear | Kanzaki |
Drive method | Dual pedal-operation |
Speed forward max | 18 km/h |
Speed reverse max | 6,8 mph |
Speed reverse max | 11 km/h |
Transmission manufacturer, front | Kanzaki |
| Battery | |
Battery capacity | 62 Ah |
Battery type | Lead-Acid |
Battery pack weight | 14 kg |
Battery manufacturer | Exide |
| Equipment | |
Seat suspension | Yes |
Seat type | Full suspension, arm rests |
Hour meter type | Digital |
Seat material | Vinyl |
Seat back height | High |
Parking brake, type | Disc |
| Sound and noise | |
Sound power level, guaranteed (LWA) | 105 dB(A) |
Sound power level, measured | 105 dB(A) |
| Emission | |
Exhaust emissions (CO₂ EU V) | 1 047 g/kWh |
