Specifications
Specifications
P 525D (2012-2014) Art no: 966 60 74‑01 | |
|---|---|
| Cutting deck | P 525D (2012-2014) Art no: 966 60 74‑01 |
| Uncut circle | 58 cm |
| Cutting width, min | 132 cm |
| Cutting width, max | 155 cm |
| Cutting height min | 30 mm |
| Cutting height max | 112 mm |
| Blade engagement | Electric clutch |
| Engine | |
| Power/fuel type | Diesel |
| Net power at preset rpm Energy | 18,7 kW |
| Motor/engine manufacturer | Kubota |
| Engine name | D1105 |
| Cylinder displacement | 1 123 cm³ |
| Cylinders | 3 |
| Engine cooling | Liquid |
| Engine lubrication type | Pressure with Oilfilter |
| Oil filter | Yes |
| Dimensions | |
| Tyre dimensions, front | 20x10-10 |
| Tyre dimensions, rear | 20x10-10 |
| Wheelbase | 106 cm |
| Ground clearance | 140 mm |
| Base machine, length | 211 cm |
| Base machine, width | 114 cm |
Gross weight towed | 350 kg |
| Weight (excl. cutting equipment) | 665 kg |
| Vibration | |
| Vibration level steering wheel | 1,7 m/s² |
| Vibration level seat | 0,7 m/s² |
| Drive system | |
| Transmission type | Hydrostatic |
| Transmission manufacturer, rear | Kanzaki |
| Drive method | Dual pedal-operation |
| Speed forward max | 18 km/h |
| Speed reverse max | 6,8 mph |
| Speed reverse max | 11 km/h |
| Transmission manufacturer, front | Kanzaki |
| Battery | |
| Battery capacity | 62 Ah |
| Battery type | Lead-Acid |
| Battery pack weight | 14 kg |
| Battery manufacturer | Exide |
| Equipment | |
| Seat suspension | Yes |
| Seat type | Full suspension, arm rests |
| Hour meter type | Digital |
| Seat material | Vinyl |
| Seat back height | High |
| Parking brake, type | Disc |
| Sound and noise | |
| Sound pressure level at operators ear | 92 dB(A) |
| Sound power level, guaranteed (LWA) | 105 dB(A) |
| Sound power level, measured | 105 dB(A) |
| Emission | |
Exhaust emissions (CO₂ EU V) | 1 047 g/kWh |
