Specifications

T35, All ex US/CA Art no: 967 68 81‑01
Capacity	T35, All ex US/CA Art no: 967 68 81‑01
Cutting width	45 cm
Engine
Output shaft power	1,4 kW
Cylinder displacement	34,6 cm³
Maximum rpm output shaft	8 300 rpm
Fuel tank volume	20,29 fl oz
Fuel tank volume	0,6 l
Dimensions
Weight (excl. cutting equipment)	5,8 kg
Tube diameter	24 mm
Product size length	178,5 cm
Equipment
Gear ratio	1,41
Drive gear angle	30 °
Harness	Not included
Saw blade	Not included
Trimmer head	T35 M10
Grass blade	Not included
Emission
Exhaust emissions (CO₂ EU V)	862 g/kWh
Vibration
Equivalent vibration level (ahv, eq) front handle	4,5 m/s²
Equivalent vibration level (ahv, eq) rear handle	3,9 m/s²
Sound and noise
Sound power level, guaranteed (LWA)	114 dB(A)
Sound pressure level at operators ear	99 dB(A)
