Specifications
Specifications
T35+Multi 330-2 (1") Art no: 967 66 06‑01 | |
|---|---|
| Capacity | T35+Multi 330-2 (1") Art no: 967 66 06‑01 |
Cutting width | 45 cm |
| Engine | |
Cylinder displacement | 33,6 cm³ |
Output shaft power | 1,2 kW |
Fuel tank volume | 0,74 l |
Fuel consumption | 639 g/kWh |
Maximum power speed | 7 000 rpm |
Idling speed | 2 500 rpm |
Maximum rpm output shaft | 8 570 rpm |
Electrode gap | 0,6 mm |
Clutch engagement speed (±120) | 3 200 rpm |
Torque, max. | 1,76 Nm |
Torque, max. at rpm | 5 000 rpm |
Spark Plug | NGK BPM7A |
| Equipment | |
Grass blade | Multi 330-2 |
Harness | Balance 35 |
Saw blade | Not included |
Trimmer head | T35 M12 |
Handle type | Bullhorn |
| Dimensions | |
Tube diameter | 28 mm |
Weight (excl. cutting equipment) | 7,1 kg |
Tube length | 1 500 mm |
| Lubricant | |
Lubricant type (Engine) | Husqvarna 2 stroke or equiv. at 50:1 |
Lubricant type (bevel gear) | Mineral grease |
| Transmission | |
Gear ratio | 1,4 |
Drive gear angle | 60 ° |
| Vibration | |
Equivalent vibration level (ahv, eq) left handle | 4,2 m/s² |
Equivalent vibration level (ahv, eq) right handle | 4 m/s² |
| Sound and noise | |
Sound pressure level at operators ear | 90 dB(A) |
Sound power level, guaranteed (LWA) | 108 dB(A) |
| Control | |
Connectivity | Not applicable |
