Parts, manuals and support for 129R
All the support you need for 129R. Manuals, spare parts, guides, how-to’s, and more.
Choose article number
To show you the right support, choose an article number from this list.
Support content
Manuals & Documents(3)
Manuals & Documents
(3)
Showing the latest version of manual and documents for 129R. For earlier versions, see link below to search all manuals & documents..
Accessories(19)
Accessories
(19)
All accessories for 129R.
Warranty
Warranty
All you need to know about Husqvarna’s warranty policy and the service provided by us within the warranty period.
Warranty policy
Warranty service
Check your warranty
Login or create an account on MyPages to check your warranty period.
MyPages
Is your product broken?
If your product is broken and you wish to claim your warranty, it must always be examined by a dealer.
Find your nearest dealer
General questions
You can always contact Husqvarna for general questions about our warranty.
Contact Husqvarna
Specifications
Specifications
T25+Grass 255-4, All ex US50, CAN Art no: 967 19 33‑01 | |
|---|---|
| Capacity | T25+Grass 255-4, All ex US50, CAN Art no: 967 19 33‑01 |
| Cutting width | 43 cm |
| Engine | |
| Cylinder displacement | 27,6 cm³ |
| Output shaft power | 0,85 kW |
| Fuel tank volume | 0,27 l |
| Fuel consumption | 604 g/kWh |
| Maximum power speed | 8 000 rpm |
| Idling speed | 2 800 rpm |
| Maximum rpm output shaft | 7 200 rpm |
| Electrode gap | 0,5 mm |
| Clutch engagement speed (±120) | 4 200 rpm |
| Spark Plug | NGK CMR6A |
| Equipment | |
| Grass blade | Grass 255-4 |
| Harness | Standard double harness |
| Saw blade | Not included |
| Trimmer head | T25 (L) |
| Dimensions | |
| Tube diameter | 25,4 mm |
| Weight (excl. cutting equipment) | 5,4 kg |
| Tube length | 1 174,16 mm |
| Emission | |
Exhaust emissions (CO₂ EU V) | 1 504 g/kWh |
| Exhaust emissions (HC average) EU | 28,2 g/kWh |
| Exhaust emissions (HC average) CARB | 31,56 g/kWh |
| Exhaust emissions (CO average) EU | 43,3 g/kWh |
| Exhaust emissions (CO average) EPA | 30,3 g/kWh |
| Exhaust emissions (NOx average) EU | 2,1 g/kWh |
| Exhaust emissions (NOx average) EPA | 1,82 g/kWh |
| Transmission | |
| Gear ratio | 19 |
| Drive gear angle | 30 ° |
| Vibration | |
| Equivalent vibration level (ahv, eq) left handle | 4,62 m/s² |
| Equivalent vibration level (ahv, eq) right handle | 6,51 m/s² |
| Sound and noise | |
| Sound pressure level at operators ear | 89 dB(A) |
| Sound power level, guaranteed (LWA) | 115 dB(A) |
