Specifications

All ex US50, CAN Art no: 952 71 56‑45
Engine	All ex US50, CAN Art no: 952 71 56‑45
Cylinder displacement	28 cm³
Output shaft power	0,8 kW
Fuel tank volume	0,5 l
Fuel consumption	575 g/kWh
Maximum power speed	8 000 rpm
Idling speed	3 000 rpm
Capacity
Air flow in housing	13,31 m³/min
Air flow in pipe	12,03 m³/min
Air speed (flat nozzle)	76 m/s
Air speed (round nozzle)	58,12 m/s
Max Blow force	12,5 N
Air speed	76 m/s
Dimensions
Weight (complete product w/o side packed articles)	4,35 kg
Sound and noise
Sound pressure level at operators ear	94 dB(A)
Sound power level, measured	109 dB(A)
Sound power level, guaranteed (LWA)	112 dB(A)
Equipment
Nozzle type	Round+ Flat
Harness	Single harness
Vacuum Kit	Yes
Vibration
Equivalent vibration level (ahv, eq) handle	11,1 m/s²
Emission
Exhaust emissions (CO₂ EU V)	1 392 g/kWh
