Leaf Blowers
Parts, manuals and support for 125BVx
All the support you need for 125BVx. Manuals, spare parts, guides, how-to’s, and more.
Choose article number
To show you the right support, choose an article number from this list.
Spare parts
Choose the part you wish to repair
Support content
Manuals & Documents
(4)
Manuals & Documents
(4)
Showing the latest version of manual and documents for 125BVx. For earlier versions, see link below to search all manuals & documents..
Accessories
(8)
Accessories
(8)
All accessories for 125BVx.
Warranty
Warranty
All you need to know about Husqvarna’s warranty policy and the service provided by us within the warranty period.
Warranty policy
Warranty service
Check your warranty
Login or create an account on MyPages to check your warranty period.
MyPages
Is your product broken?
If your product is broken and you wish to claim your warranty, it must always be examined by a dealer.
Find your nearest dealer
General questions
You can always contact Husqvarna for general questions about our warranty.
Contact Husqvarna
Specifications
Specifications
All ex US50, CAN Art no: 952 71 56‑45 | |
|---|---|
| Engine | All ex US50, CAN Art no: 952 71 56‑45 |
Cylinder displacement | 28 cm³ |
Output shaft power | 0,8 kW |
Fuel tank volume | 0,5 l |
Fuel consumption | 575 g/kWh |
Maximum power speed | 8 000 rpm |
Idling speed | 3 000 rpm |
| Capacity | |
Air flow in housing | 13,31 m³/min |
Air flow in pipe | 12,03 m³/min |
Air speed (flat nozzle) | 76 m/s |
Air speed (round nozzle) | 58,12 m/s |
Max Blow force | 12,5 N |
Air speed | 76 m/s |
| Dimensions | |
Weight (complete product w/o side packed articles) | 4,35 kg |
| Sound and noise | |
Sound pressure level at operators ear | 94 dB(A) |
Sound power level, measured | 109 dB(A) |
Sound power level, guaranteed (LWA) | 112 dB(A) |
| Equipment | |
Nozzle type | Round+ Flat |
Harness | Single harness |
Vacuum Kit | Yes |
| Vibration | |
Equivalent vibration level (ahv, eq) handle | 11,1 m/s² |
| Emission | |
Exhaust emissions (CO₂ EU V) | 1 392 g/kWh |
