Parts, manuals and support for YTA24V48
All the support you need for YTA24V48. Manuals, spare parts, guides, how-to’s, and more.
Choose your SKU
For more product support please choose your SKU below.
Support content
Manuals & Documents(1)
Manuals & Documents
(1)
Showing the latest version of manual and documents for YTA24V48. For earlier versions, see link below to search all manuals & documents..
Accessories(1)
Accessories
(1)
All accessories for YTA24V48.
Troubleshooting & help(10)
Troubleshooting & help
(10)
Frequently read self-service articles about YTA24V48.
Warranty
Warranty
All you need to know about Husqvarna’s warranty policy and the service provided by us within the warranty period.
Warranty policy
Warranty service
Check your warranty
Login or create an account on MyPages to check your warranty period.
MyPages
Is your product broken?
If your product is broken and you wish to claim your warranty, it must always be examined by a dealer.
Find your nearest dealer
General questions
You can always contact Husqvarna for general questions about our warranty.
Contact Husqvarna
Specifications
Specifications
YTA24V48 TRACTOR Art no: 960 43 02‑14 | |
|---|---|
| Cutting deck | YTA24V48 TRACTOR Art no: 960 43 02‑14 |
| Cutting width | 48 in |
| Nose roller | Yes |
| Anti-scalp wheels | 4 |
| Engine | |
| Cylinder displacement | 44.2 cu.inch |
| Motor/engine manufacturer | Briggs & Stratton |
| Engine name | Intek |
| Net power at preset rpm Energy | 17.9 kW |
| Net power at preset rpm | 3,300 rpm |
| Cylinders | 2 |
| Generator | 16 A |
| Power/fuel type | Petrol |
| Oil filter | Yes |
| Drive system | |
| Drive method | Pedal-operated |
| Speed reverse max | 2.9 mph |
| Equipment | |
| Seat material | Vinyl |
| Front-End Protection | Optional |
| Hour meter type | Digital with pre-programmed service intervals |
| Seat back height | High |
| Steering wheel type | Deluxe Overmolded |
| Collector | Available as accessory |
| Transmission | |
| Transmission type | Fast CVT |
| Transmission manufacturer | General Transmission |
