Product Description
The Husqvarna V500 series stand-on mower represents maximum efficiency in commercial mowing. Providing zero turn capability, rapid mount-dismount, unbeatable maneuvering and ergonomic operation, operators have the best of zero turn and commercial walk behind combined. Heavy duty construction combined with industrial strength drive systems deliver maximum durability in any commercial application.
Product Information
Stand between the axles
Stand between the axles for better balance and traction
Flip-up platform
Flip-up platform for walk behind mode
Kawasaki FX series V-twin engine
Cast aluminium spindles
Cast aluminium spindles
High leverage deck lift
High leverage deck lift for ease of use
Tool-less removal of operators cushion
Flip down tool-less removal of operator cushion
Palm deck release
Palm deck release for ease of deck lowering
Operators console
Ergonomic layout of the operator console
Heavy Duty Cutting Deck
Compare specifications and features with similar Husqvarna products.
CompareStandard SKU: 970 73 39‑01 | |
|---|---|
| Cutting System | Standard SKU: 970 73 39‑01 |
| Cutting width | 48 in |
| Cutting deck type | 7-gauge fabricated |
| Cutting methods | Collect/Mulch/Side discharge |
| Cutting deck material | Steel |
| Deck thickness | 7 gauge |
| Cutting height steps | 14 |
| Blade engagement | Electric clutch |
| Blade-tip speed | 18,500 fpm |
| Blade-tip speed | 94 m/s |
| Blades | 3 pcs |
| Anti-scalp wheels | 3 |
| Nose roller | No |
| Deck lifting system | Manual, foot activated |
| Powder-coated cutting deck | Yes |
| Spindle/mandrel type | Aluminium, commercial |
| Greasable mandrels | Yes |
| Deck Wash Port | No |
| Approval | |
| Homeowner Warranty | 5 Years or 1500 Hours |
| Commercial Warranty | 5 Years or 1500 Hours |
| Capacity | |
| Productivity | 3.7 acres/hr |
| Speed forward max | 10 mph |
| Speed forward min | 0 mph |
| Dimensions | |
| Base machine, height | 48 in |
| Base machine, length | 57 in |
| Base machine, width (chute down) | 62 in |
| Base machine, width (chute up) | 50 in |
| Weight | 1,140 lbs |
| Drive system | |
| Transmission type | Pump/Wheel motor |
| Transmission manufacturer | Hydro-Gear/Parker |
| Transmission model | HP1/DL |
| Pump displacement | 12 cm³ |
| Fan-cooled pumps | Yes |
| Engine | |
| Motor/engine manufacturer | Kawasaki |
Engine Power (As rated by the engine manufacturer) | 24.5 hp |
| Engine name | FX Series V-Twin |
| Cylinder displacement | 52 cu.inch |
| Cylinders | 2 |
| Engine cooling | Air |
| Air filter type | Heavy-Duty Canister Style |
| Power/fuel type | Gasoline |
| Engine lubrication type | Full pressure with oil filter |
| Oil filter | Yes |
| Fuel tank volume (with reserve) | 7 gal (US) |
| Fuel tank location | Side (Single) |
| Equipment | |
| Seat material | Vinyl |
| Seat back height | Low |
| Hour meter type | Yes |
| Cup holder | Yes |
| Seat type | Professional |
Operator’s Manuals
