Specifications
Specifications
Backpack Float Carb Art no: 967 84 33‑01 | |
---|---|
Capacity | Backpack Float Carb Art no: 967 84 33‑01 |
Cutting width | 43 cm |
Engine | |
Cylinder displacement | 32.6 cm³ |
Output shaft power | 0.9 kW |
Fuel tank volume | 1.15 l |
Fuel consumption | 550 g/kWh |
Maximum power speed | 7,000 rpm |
Idling speed | 2,700 rpm |
Maximum rpm output shaft | 10,000 rpm |
Electrode gap | 0.6 mm |
Clutch engagement speed (±120) | 4,320 rpm |
Torque, max. | 1.15 Nm |
Torque, max. at rpm | 7,000 rpm |
Spark Plug | NGK BPM7A |
Equipment | |
Grass blade | Multi 330-2 |
Harness | Single harness |
Saw blade | Not included |
Trimmer head | Not included |
Handle type | Loop / back-pack frame |
Dimensions | |
Tube diameter | 26 mm |
Weight (excl. cutting equipment) | 10.2 kg |
Tube length | 1,495 mm |
Lubricant | |
Lubricant type (Engine) | Husqvarna 2 stroke or equiv. at 50:1 |
Lubricant type (bevel gear) | Mineral grease |
Transmission | |
Gear ratio | 0.74 |
Drive gear angle | 30 ° |
Vibration | |
Equivalent vibration level (ahv, eq) left handle | 4.58 m/s² |
Equivalent vibration level (ahv, eq) right handle | 2.58 m/s² |
Sound and noise | |
Sound pressure level at operators ear | 92.4 dB(A) |
Sound power level, guaranteed (LWA) | 115 dB(A) |
Control | |
Connectivity | Not applicable |
