Parts, manuals and support for 135 Mark II
All the support you need for 135 Mark II. Manuals, spare parts, guides, how-to’s, and more.
Choose article number
To show you the right support, choose an article number from this list.
Support content
Manuals & Documents(1)
Manuals & Documents
(1)
Showing the latest version of manual and documents for 135 Mark II. For earlier versions, see link below to search all manuals & documents..
Warranty
Warranty
All you need to know about Husqvarna’s warranty policy and the service provided by us within the warranty period.
Warranty policy
Warranty service
Check your warranty
Login or create an account on MyPages to check your warranty period.
MyPages
Is your product broken?
If your product is broken and you wish to claim your warranty, it must always be examined by a dealer.
Find your nearest dealer
General questions
You can always contact Husqvarna for general questions about our warranty.
Contact Husqvarna
Specifications
Specifications
16" 3/8 S93G SN Art no: 967 86 18‑46 | |
|---|---|
| Engine | 16" 3/8 S93G SN Art no: 967 86 18‑46 |
| Chain speed at max power | 16.8 m/s |
| Cylinder displacement | 38 cm³ |
| Output shaft power | 1.6 kW |
| Dimensions | |
| Weight (excl. cutting equipment) | 4.68 kg |
| Equipment | |
| Recommended bar length, min | 35 cm |
| Recommended bar length, max | 40 cm |
| Pitch | 3/8" mini |
| Chain type | S93G |
| Bar length | 40 cm |
| Bar length (inch) | 16 in |
| Emission | |
Exhaust emissions (CO₂ EU V) | 804 g/kWh |
| Vibration | |
| Equivalent vibration level (ahv, eq) front handle | 3.72 m/s² |
| Equivalent vibration level (ahv, eq) rear handle | 5.5 m/s² |
| Sound and noise | |
| Sound pressure level at operators ear | 102 dB(A) |
| Sound power level, guaranteed (LWA) | 116 dB(A) |
