Specifications
Specifications
EU Art no: 967 65 92‑01 | |
|---|---|
| Engine | EU Art no: 967 65 92‑01 |
| Cylinder displacement | 21.7 cm³ |
| Output shaft power | 0.6 kW |
| Fuel consumption | 620 g/kWh |
| Fuel tank volume | 0.45 l |
| Maximum power speed | 7,800 rpm |
| Dimensions | |
| Product size length | 121.4 cm |
| Weight (complete product w/o side packed articles) | 5 kg |
| Equipment | |
| Knife length | 75 cm |
| Teeth opening | 30 mm |
| Emission | |
Exhaust emissions (CO₂ EU V) | 1,344 g/kWh |
| Vibration | |
| Equivalent vibration level (ahv, eq) rear handle | 1.8 m/s² |
| Equivalent vibration level (ahv, eq) front handle | 2.9 m/s² |
| Sound and noise | |
| Sound power level, guaranteed (LWA) | 102 dB(A) |
| Sound pressure level at operators ear | 93 dB(A) |
| Control | |
| Connectivity | Not applicable |
| Capacity | |
| Cutting speed | 4,400 cut/min |
