Commercial Robotic Lawn Mowers

Husqvarna Automower® 520 EPOS®

€3,999.00
5,000 m²
Area capacity
Virtual wire
Boundary type
Husqvarna Fleet Services
App controlled
€3,999.00 - Price includes
Husqvarna Automower® 520 EPOS® - 970 71 78‑03

Included

  • Charging station
    Yes
  • Extra blades
    6 pcs
  • Wheel brushes
    Yes
  • Power supply unit
    Yes
  • Low voltage cable
    10 m

Not included

  • Reference Station

Robotic mower with virtual boundaries for green areas up to 5000 m²

Husqvarna Automower® 520 EPOS® is a robotic mower designed for commercial fleet use and a sibling model to the well-established Automower® 550 EPOS®. It features Husqvarna EPOS® with virtual boundaries instead of physical wires, allowing you to define several work areas with different settings and set temporary stay-out zones. Thanks to the systematic mowing pattern, Automower® 520 EPOS® can handle green areas of up to 5000 m². The mower also navigates easily in narrow passages and manages slopes up to 45% (24°) with perfect cutting results – even in rainy conditions. EPOS® RS5 Reference Station required.
Features

Adjustable virtual boundaries

Customisable lawn maintenance thanks to wire free installation with virtual boundaries.

Husqvarna EPOS® wire-free Technology

Virtual, wire-free operation through satellite based RTK-GNSS technology, enables an accuracy down to approximately 2cm. The absence of physical wires implies a new level of robustness and flexibility.

Selectable mowing pattern

Improve the visual impression of the turf by changing the mowing pattern. With EPOS® technology, the mower can run in parallel lines and create a variety of patterns, such as diamonds, triangles and checkerboard.

Warning lights

Warning lights with pulsating or solid light to create awareness during operation at night.

Husqvarna Fleet Services™

Husqvarna Fleet Services™ gives you full control of the mower with the possibility to monitor, control and analyze your entire fleet of products from your smartphone, tablet or laptop.

Pro user interface

Interface adapted for professional remotely handling through Husqvarna Fleet Services. Controls on product; status LED indication and START / STOP functionality.

Customized work areas

The fully connected product provides an opportunity to individually customize each work area with a unique time schedule, cutting height and cutting pattern. Provides tailored care for a site with multiple scattered areas.

Temporary stay-out zones

When the need arises, create temporary stay-out zones in your robot installation. Practically useful if part of the surface area needs to be restricted for a temporary construction work, seeding or during events.

EPOS® guidance

Automatically calculates the most efficient route to and from the charging station’s docking point.

Maintenance point

Designate and mark a machine maintenance parking spot on the map. On command, the product parks there automatically while waiting for service, cleaning, loading or storage.

appDrive - operate by remote

Seize the opportunity to operate the product using a remote control via the appDrive feature on your smartphone. An excellent assistance when the product needs to be moved between workspaces, to the service facility, or during installation.

Electric height adjustment - PATENTED

Electric cutting height adjustment makes it convenient to set the desired height via the Husqvarna Automower® Connect app.

Weather timer

Adjusts the working time to the lawn’s growth rate, which decreases wear on lawn and mower.

5 blade cutting disc

The cutting discs on the commercial models, Automower 500-series and CEORA, are equipped with 5 Enhance HSS blades, which gives a higher cutting performance.

Unique cutting system

Equipped with sharp razor-like blades mounted on a robust cutting disc system for best cutting performance and low energy consumption.

Balance control

Automatically detects and notifies if imbalance in the cutting system occur to ensure trouble-free operation.

Manages slopes up to 45%

Large coarse-tread wheels provide excellent traction on slopes up to 45%.

FOTA – Firmware Over-The-Air

FOTA – a technology that enables the operators to perform upgrades of the firmware, via the Fleet Services app.

Theft protection by GPS

Equipped with GPS based geofence including flash notifications to your devices.

Safety sensors

Equipped with several safety sensors, including an automatic and immediate shutdown of the cutting function if the unit tips over or is lifted from the ground. If Automower® encounters any obstacles, it stops or changes direction, further ensuring its mowing mission.

Weatherproof design

Designed to operate 24/7 throughout the grass growing season, with normal maintenance and cleaning. The unique cutting system, with free-hanging razor blades on a cutting disc, ensures the cutting result even in rainy conditions.

Specifications
Compare specifications and features with similar Husqvarna products.
Compare

GB, IE

Art no: 970 71 78‑03

Capacity
GB, IE
Art no: 970 71 78‑03
Area capacity5,000 m²
Boundary typeVirtual wire
Maximum slope performance at boundary15 %
Maximum slope performance inside installation45 %
Max active time24 h
Follow guideVirtual transport path
Charging systemAutomatic
Overall dimensions
Weight (complete product w/o side packed articles)13.8 kg
Product size length72 cm
Product size width56 cm
Product size height32 cm
Product data
ColourOrange
Sound level perceived62
Protection Index (IP Code)IPX4
Battery typeLi-Ion
Battery capacity5 Ah
Charging current2.2 A
Typical mow time on one charge75 min
Typical charging time65 min
Mean energy consumption per month at maximum use14 kWh
Area capacity - Standard 485,000 m²
Area capacity - Sports 242,500 m²
Area capacity - Max 727,500 m²
Area capacity per hour without charging175 m²
Cutting System
Cutting system5 pivoting razor blades
Cutting height max60 mm
Cutting height min20 mm
Cutting width24 cm
Cutting height adjustmentElectric
Skid plateYes
Dual cutting directionYes
Control
User InterfaceProfessional User Interface/App
DisplayNone
ConnectivityBluetooth®, Cellular
App controlledHusqvarna Fleet Services
Smart Home integrationYes
Firmware UpdateFOTA
Safety
GPS Theft trackingYes
GeoFenceYes
PIN codeYes
AlarmHigh
Lift sensorYes
Tilt sensorYes
Object detectionNo
Services
Owner support
Manuals, handbooks, spare parts, guides, and related information for Automower® 520 EPOS® can be found in the product support.
