1/2
12.4 kg
Weight (excl. cutting equipment)
1.4 kW
Output shaft power1
Product variant
535FBK CHAINSAW
Art no: 966 06 32‑02
Art no: 966 06 32‑02
HUSQVARNA 535FBx - 966 06 32‑02
Included
- HarnessIntegrated
Application particulary suitable for efficient top spacing
Husqvarna 535FBx is the first application for top spacing. The design provide total load distribution, the engine is located in a harness on the user's back. The cutting equipment is hinged in a flexible suspension for best comfort and flexibility, to make work easy with high precision.
Features
Features
Total load distribution
Total load distribution
Flexible saw suspension
Flexible saw suspension
X-Torq® engine
Great power and efficiency
Auto return stop switch
When the stop switch has been used, it is automatically reset to ON to facilitate the next start.
Ergonomic handle
Comfortable curved handle and shaft for easier use and increased maneuverability
Comfort handle
Comfortable handles
LowVib®
LowVib® sparing the user’s arms and hands
Fuel pump
Air purge removes air from carburetor and fuel system for easy starting
Chain lubrication
Adjustable, automatic chain lubrication
Detachable shaft
Easily breaks down for safer transport and compact storage
Adjustable handle bar
Adjustable handle bar for best comfort
Specifications
Specifications
Compare specifications and features with similar Husqvarna products.
Compare535FBK CHAINSAW Art no: 966 06 32‑02 | ||
|---|---|---|
| Engine | 535FBK CHAINSAW Art no: 966 06 32‑02 | All ex US50 Art no: 966 06 32‑03 |
Output shaft power1 | 1.4 kW | 1.4 kW |
Cylinder displacement | 34.6 cm³ | 34.6 cm³ |
Fuel tank volume | 0.6 l | 0.6 l |
Fuel consumption | 475 g/kWh | 475 g/kWh |
Maximum power speed | 8,400 rpm | 8,400 rpm |
Idling speed | 2,900 rpm | 2,900 rpm |
Maximum rpm output shaft | 8,220 rpm | 8,220 rpm |
| Equipment | ||
Harness | Integrated | |
| Transmission | ||
Gear ratio | 1.29 | 1.29 |
| Dimensions | ||
Weight (excl. cutting equipment) | 12.4 kg | 12.4 kg |
Tube diameter | 24 mm | 24 mm |
| Sound and noise | ||
Sound power level, guaranteed (LWA) | 111 dB(A) | 111 dB(A) |
Sound pressure level at operators ear | 94 dB(A) | 94 dB(A) |
| Emission | ||
Exhaust emissions (CO₂ EU V)2 | 862 g/kWh | 862 g/kWh |
Services
Services
Owner support
Owner support
Manuals, handbooks, spare parts, guides, and related information for 535FBX can be found in the product support.
Product support for 535FBXDisclaimer:
- 1Output shaft power: Net power rating as per ISO 8893, at specified RPM
- 2Exhaust emissions (CO₂ EU V): This CO2 measurement results from testing over a fixed test cycle under laboratory conditions a(n) (parent) engine representative of the engine type (engine family) and shall not imply or express any guarantee of the performance of a particular engine.
