Parts, manuals and support for AUTOMOWER® 535 AWD

All the support you need for AUTOMOWER® 535 AWD. Manuals, spare parts, guides, how-to’s, and more.

Choose your SKU

For more product support please choose your SKU below.

SKU

Support content

Accessories

(11)

All accessories for AUTOMOWER® 535 AWD.

Warranty

All you need to know about Husqvarna’s warranty policy and the service provided by us within the warranty period.

If your product is broken and you wish to claim your warranty, it must always be examined by a dealer.
Find your nearest dealer

You can always contact Husqvarna for general questions about our warranty.
Contact Husqvarna

Specifications

With standard installation available Art no: 967 85 34‑05
Cutting System	With standard installation available Art no: 967 85 34‑05
Cutting system	3 pivoting razor blades
Cutting width	22 cm
Skid plate	Yes
Dual cutting direction	Yes
Capacity
Area capacity	3,500 m²
Maximum slope performance at boundary	50 %
Maximum slope performance inside installation	70 %
Max active time	24 h
Search system	Pentasearch
Follow guide	3
Control
User Interface	Professional User Interface/App
Display	None
Smart Home integration	Yes
Firmware Update	FOTA
Product data
Sound level perceived	60 dB(A)
Protection Index (IP Code)	IPX4
Typical mow time on one charge	100 min
Mean energy consumption per month at maximum use	24 kWh
Overall dimensions
Weight (complete product w/o side packed articles)	17 kg
Product size length	93 cm
Product size width	55 cm
Product size height	29 cm
Safety
GPS Theft tracking	Yes
PIN code	Yes
Lift sensor	Yes
Tilt sensor	Yes
