Parts, manuals and support for 525HE4

All the support you need for 525HE4. Manuals, spare parts, guides, how-to’s, and more.

Choose your SKU

For more product support please choose your SKU below.

SKU

Support content

Manuals & Documents

(3)

Showing the latest version of manual and documents for 525HE4. For earlier versions, see link below to search all manuals & documents..

Warranty

All you need to know about Husqvarna’s warranty policy and the service provided by us within the warranty period.

If your product is broken and you wish to claim your warranty, it must always be examined by a dealer.
Find your nearest dealer

You can always contact Husqvarna for general questions about our warranty.
Contact Husqvarna

Specifications

All excl. CN Art no: 967 94 51‑01
Engine	All excl. CN Art no: 967 94 51‑01
Cylinder displacement	25.4 cm³
Output shaft power	1 kW
Fuel consumption	600 g/kWh
Fuel tank volume	0.5 l
Maximum power speed	8,500 rpm
Dimensions
Length, transportation mode - metric	192 cm
Weight (complete product w/o side packed articles)	6.3 kg
Equipment
Knife length	60 cm
Teeth opening	30 mm
Emission
Exhaust emissions (CO₂ EU V)	1,141 g/kWh
Vibration
Equivalent vibration level (ahv, eq) rear handle	3.9 m/s²
Equivalent vibration level (ahv, eq) front handle	4.6 m/s²
Sound and noise
Sound power level, guaranteed (LWA)	107 dB(A)
Sound pressure level at operators ear	95 dB(A)
Control
Connectivity	Not applicable
Capacity
Cutting speed	4,400 cut/min
