Specifications
Specifications
R 200iX RIDER Art no: 970 64 99‑01 | |
|---|---|
| Cutting deck | R 200iX RIDER Art no: 970 64 99‑01 |
| Uncut circle | 40 cm |
| Cutting width, min | 94 cm |
| Cutting width, max | 103 cm |
| Cutting height min | 25 mm |
| Cutting height max | 75 mm |
| Blade engagement | Electric |
| Engine | |
| Power/fuel type | Battery |
| Dimensions | |
| Tyre dimensions, front | 170/60-8 |
| Tyre dimensions, rear | 170/60-8 |
| Wheelbase | 90.7 cm |
| Ground clearance | 100 mm |
| Base machine, length | 199 cm |
| Base machine, width | 89 cm |
| Base machine, height | 113 cm |
Gross weight towed | 110 kg |
| Weight (excl. cutting equipment) | 187 kg |
| Vibration | |
| Vibration level steering wheel | 0.13 m/s² |
| Vibration level seat | 0.23 m/s² |
| Drive system | |
| Transmission type | Electric |
| Drive method | Dual pedal-operation |
| Speed forward max | 9.5 km/h |
| Speed reverse max | 3.1 mph |
| Speed reverse max | 5 km/h |
| Battery | |
| Battery capacity | 38.5 Ah |
| Battery type | Li-Ion |
| Battery pack weight | 17 kg |
| Battery manufacturer | Husqvarna |
| Equipment | |
| Seat suspension | Yes |
| Seat type | Comfort |
| Hour meter type | Digital |
| Seat material | PU |
| Seat back height | Medium |
| Foldable seat | Yes |
| Steering wheel type | Ergonomic |
| Parking brake, type | Electric |
| Sound and noise | |
| Sound pressure level at operators ear | 78.2 dB(A) |
| Sound power level, guaranteed (LWA) | 96 dB(A) |
| Sound power level, measured | 95 dB(A) |
