1/3
2.3 cu.inch
Cylinder displacement
2.1 hp
Power output
55 fts
Chain speed at max power
What's Included
What's Included
HUSQVARNA 135 Mark II - 967 86 18‑16
Included
- Nose typeSprocket nose
- SpikesMounted
- Chain typeS93G
- Bar length (inch)16 in
Easy-to-use and powerful chainsaw with quick start
Get the job done the first time with the Husqvarna 135 Mark II. This reliable gas saw features Smart Start® and LowVib® technology for easy, comfortable use. Our proprietary X-TORQ® engine delivers superior performance, increased fuel efficiency and low emissions. And Air Injection™ technology improves engine life by expelling larger dust and debris particles before they reach the air filter.
Features
Features
Specifications
Specifications
Compare specifications and features with similar Husqvarna products.
Compare16" 3/8 S93G SN, US/CASKU: 967 86 18‑16 | |
---|---|
Engine | 16" 3/8 S93G SN, US/CA SKU: 967 86 18‑16 |
Chain speed at max power | 55 fts |
Cylinder displacement | 2.3 cu.inch |
Power output | 2.1 hp |
Torque, max. | 1.84 Nm |
Torque, max. at rpm | 8,000 rpm |
Clutch engagement speed (±120) | 4,000 rpm |
Electrode gap | 0.022 in |
Idling speed | 3,000 rpm |
Ignition module air gap | 0.012 in |
Maximum power speed | 9,000 rpm |
Oil pump type | Automatic |
Spark Plug | NGK BPMR7A |
Equipment | |
Recommended bar length, min | 14 in |
Pitch | 3/8" mini |
Recommended bar length, max | 16 in |
Chain type | S93G |
Bar length | 40 cm |
Bar length (inch) | 16 in |
Sprocket type | Spur 6 |
Gauge | .050" |
Dimensions | |
Weight (excl. cutting equipment) | 10.36 lbs |
Sound and noise | |
Sound pressure level at operators ear | 102 dB(A) |
Sound power level, guaranteed (LWA) | 116 dB(A) |
Sound power level, measured | 114.34 dB(A) |
Vibration | |
Equivalent vibration level (ahv, eq) rear handle | 5.5 m/s² |
Equivalent vibration level (ahv, eq) front handle | 3.72 m/s² |
Lubricant | |
Oil tank volume | 0.549 US pint |
Lubricant type (Engine) | Husqvarna 2 stroke or equiv. at 50:1 |
Emission | |
Exhaust emissions (CO₂ EU V) | 804 g/kWh |
Reviews
Reviews
Services
Services
Owner support
Owner support
Manuals, handbooks, spare parts, guides, and related information for 135 Mark II can be found in the product support.
Product support for 135 Mark II
